Providing Sustainable Medical Solutions!
Hypodermic syringe designs vary from the syringe to syringe. Nonetheless, what remains the same is a barrel, plunger, needle, and cap. The hypodermic needle barrel holds the injected or removed substance. The plunger has a tube in it, which is why it is moveable. However, the design of the syringe depends upon the application it serves. Allied Way (India) manufactures high-quality medical syringe manufacturing machines by utilising authentic raw materials and giving effective design for better output. We are the top Medical Needle Making Machine Manufacturers In India because of our sustainable approach to manufacturing medical equipment and complying with each regulatory body.
Since 2000,
Operating in India.
Features Of Product
Our manufactured products come with distinctive specifications and with room for higher upgradation and customisations. Given below are our product's specifications and if you need assistance in understanding the configurations, reach out to us!
Call Us Now
+91-8447962638
Mail Us
vivek@alliedwayindia.com
Specifications of Our Product
- NEEDLE MACHINE SPECIFICATION
-
Basic specification Applicable range 16G-26G Capacity 68000-70000pcs/hrs M/C dimension 11.5M*3.3M*1.8M M/C weight 3000kgs Electric power 415V(50HZ ) Electric power consumption About 13kw Air pressure > 0.6Mpa Air consumption 1500ML/min Main frame material SS41 Electoless plating (base) Stainless steel (body cover) Part section material SS41 Electoless plating S45C Chrome plating A16061 Chromate Jig 60pin,420pcs Alarm system Tower lamp,Buzzer,Segment, Touch screen massage No. of worker 2 Production Hub supply -Hub press-Electric discharge -cannula assembly -epoxy bonding -Epoxy harderning -silicone coating -point Inspection -blockage needle test-badness Eject -cap assembly -cap press-Product Ejector
The Robust Construction Of Needle Manufacturing Machine!
Needles for hypodermic syringes consist of pharmacologically inert biocompatible materials because of their proximity to the body's interior.
They also need to be safe and easy to sterilise. Hypodermic needles come in many shapes, sizes, and styles, and are made from a broad array of materials. Needles are often fabricated from heat-treatable stainless steel or carbon steel.
Additionally, plastic plunger handles with a synthetic rubber plunger head are also commercially available. Allied Way (India) is one of the reliable Medical Needle Making Machine Suppliers. Since our inception in 2000, we have envisioned producing sustainable and environmentally friendly products to benefit people at large. That is why we run rigorous checks and balances on our medical disposable syringe making machines before supplying them to retailers.
Effective Solutions
Our products come with premium quality raw materials and advanced features like precision moulding, automation and controls, and much more. By investing in our products, you are going to have a higher ROI. Below are some of the standard features
- NEEDLE MACHINE SPECIFICATION
-
Part Description Hub Assembly unit Shut type
Used Ringblower hub supplyChina (Yuwei) Electric discharge treatment unit 20,000V Cannula loading station Two cannuals loading stations
With three platesCannula assembly unit Lift type,Vacuum type Epoxy Bonding unit Shut type
Used Ringblower hub supplyHub Assembly unit Wheel type
Moving type→Electric actuatorsInspection Blockage,Bending inspection
Camera(Keyence)Point inspection Point,Non-Cannula inspection
Camera(keyence)Ejection of bad needle unit Auto Eject
- NEEDLE MACHINE SPECIFICATION
-
Main parts brand Electric motor STS China Air cylinder SMC Japan Air solenoid valve Jinqi Taiwan Camera processing Keyence Japan PLC Keyence Japan Servo Panasonic Japan Touch Screen(TAIWAN) KINCO Taiwan
